F105A Residential Water Softener Valves
Featuring a flow rate of 2m³/h, the F105 achieves different functions, including service, backwash, brine & slow rinse, brine refill and fast rinse through parameter modifications.
| Model | F105A/B (82602EA)/82602EB) |
| Inlet/outlet | G 3/4 |
| Drain | 1/2 |
| Brine line connector | G 3/8 |
| Mounting base | 2.5"-8NPSM |
| Riser pipe | 1.05"OD |
| Flow rate | 2m³/h (0.1Mpa pressure difference) 3m³/h （0.3Mpa pressure difference） |
| Filter tank | 6"--12" |
| Water pressure | 0.15-0.6Mpa |
| Water temperature | 5-50℃ |
| Water turbidity | ＜2FTU |
| Ambient temperature | 5-50℃ |
| Relative humidity | ≤95%（25℃） |
| Power adapter | Input AC100~240V/50~60HZ Output DC12V/1.5A |
