F95B1/B3 Automatic Multiport Filter Valves
The F95B1/B3 operates with a flow rate of 20m³/h and features a planar and corrosion resistant gasket for opening and closing. This product is equipped with two cores. One controls the inflow of the water, while the other handles outflow. Service, backwash, and fast rinse functions can be realized through parameter modification of the valve. The F95B1 is a timer clock type while the F95B3 is a meter type.
| Model | F95B1/B3（53520/53620） |
| Regeneration | Time clock type / meter type |
| Mount type | Side mount |
| Inlet/outlet | 2"M |
| Drain | 2"M |
| Mounting base | Side mount， Top and bottom distributor basket2"M |
| Riser pipe | Side mount， Top and bottom distributor basket2"M |
| Flow rate | 20m³/h |
| Filter tank | 28"--40" |
| Water pressure | 0.2-0.6MPa |
| Water temperature | 5-50℃ |
| Water turbidity | ＜20FTU |
| Power adapter | InputAC100~240V/50~60HZ OutputDC24V/1.5A |
| Application | Activated carbon filter, sand filter |
| Filter media | Quartz sand, activated carbon |
