F111 Automatic Multiport Softener Valves
The F111A1 automatic multiport softener valve is timer clock type while the F111A3 is a meter type. Featuring a flow rate of 20m³/h, the F111A1/A3 is equipped with two valve cores, one controlling the inflow of water and brine, the other controlling outflow and drainage.
| Model | F111A1/F111A3（63520T/63620T） |
| Inlet/outlet | 2" M |
| Drain | 1.5" M |
| Brine line connector | 3/4"M |
| Mounting base | 4" -8UN |
| Riser pipe | 2" D-GB(Outer diameter63mm) |
| Flow rate | 20m³/h |
| Filter tank | 28"--40" |
| Water pressure | Up-flow |
| Water temperature | 0.2-0.6MPa |
| Water turbidity | 5-50℃ |
| Inlet/outlet | ＜5FTU |
| Ambient temperature | 5℃--50℃ |
| Relative humidity | ≤95%（25℃） |
| Power adapter | Input AC100~240V/50~60HZ Output DC24V/1.5A |
Notes: F111A1 is time clock type, F111A3 is meter type.
