RL-Q01A&RL-Q02A Automatic Backwash Disk Pre-filter
The automatic backwash disk pre-filter automatically removes sediment, rust, and other particles and contaminates from raw water with a filtering precision of 50μm. The backwash will automatically actuate itself when the filtering meter or the time becomes equal to what had been previously set. During this process, the disk will also become cleaned when the machine provides unfiltered water.
| Model | RL-Q01A | RL-Q02A |
| Filtration accuracy | 50μm | 50μm |
| Type of water | tap water | tap water |
| Suitable water pressure | 0.1-0.6MPa | 0.1-0.6MPa |
| Direct drinking | no | no |
| Rated flow rate | 1.5m³/h | 2.5m³/h |
| Diameter at the inlet and outlet | G3/4 | G1 |
| Drain line diameter | 16.5mm | 20mm |
Explosion resistant valve housing is made of a transparent plastic, while the disks are made of a food grade PP plastic certified by the NSF.
Features
1. Equipped with a check valve which prevents backflow during the water shut-down and avoids water treatment unit damage because of low pressure.
2. Inlet , Outlet and drainage can be rotated by 360°for installation.
3. Carried with a LED light which will be on when touching any button and will be off if no operation during 4 minutes.
